Home Electric Vehicle Motor Controller Auxiliary Motor Controller For All Types of Vehicle Auxiliary motor controller (Oil pump/ Hydraulic pump/ Gas pump/ Power steering pump/ DCDC/ Power distribution

Auxiliary motor controller (Oil pump/ Hydraulic pump/ Gas pump/ Power steering pump/ DCDC/ Power distribution

Meet various vehicles applications

By the end of June 2018, more than 200,000 units/sets have been used in various vehicle types;

Passenger vehicle (bus/commuter): small sea lion, Coster, 8.5m-12m passenger bus, 18m dual source trolleybus

Trucks: mini van and mini truck under 2.5 tons, 3.5-7.5 tons light trucks, 18-55 tons heavy trucks

Special-Purposed vehicles: sanitation truck, sprinkler truck, dust suppression truck, dock tractor, tunnel engineering tractor

Passenger car: A-class sedan, SUV

  • Sample provide:

    YES
  • Sample freight payer:

    Buyer
  • Term of payment:

    T/T, L/C, D/P
  • Customized:

    YES
  • Warranty:

    24 Months
  • Delivery Time:

    14-30 working days for customized EV motor controller
  • Transportation:

    Express · Sea freight · Land freight · Air freight
  • Package:

    Standard Export Package Carton/Wood
  • Availability:

    OEM/ODM, Minmum Order Request
  • Place of Origin:

    China
  • Shipping Port:

    Shandong
  • Certification:

    CE, EAC, ISO9001, OHSAS18001, TS16949, SGS
  • Product Description

LCGK Auxiliary MCU Inverter


V6-H-4D5.5G & V6-H-4D5.5G

Four-in-one Auxiliary Motor Controller (Oil pump + Vacuum pump + DC/DC + Power Distribution)


Technical Parameter

Applicable motor type

Permanent magnet synchronous motor、Three phase asynchronous motor

Applicable vehicle type

Medium BusLarge BusLogistics Vehicle

Product type

V6-H-4D5.5G & V6-H-4D5.5G

Rated input voltage

DC 540V

Rated power

5.5kW & 5.5kW & 3kW

Input voltage range

DC ;350V~750V

Rated output current

13A & 13A , DC ;27.5V/110A

Maximum output current

19.5A & 19.5A , DC 130A

Output frequency range

0~300Hz

Protection level

IP67

Cooling type

Water cooling

Outline dimension

609*473*188(mm)

Weight

35kg



Outline dimension



Application











Shandong LCGK Technologies Co.,Ltd. is committed to R&D, manufacturing of frequency inverters, servo drives, electric vehicle motor controllers, etc.


In China's first design, production and sale of "Electrical Multi-in-One Integrated Products“,and It has become the mainstream of Electric Van MCU Inverter market. LCGK Electric Vehicle Motor Drive are Widely used in new energy passenger cars, commercial vehicles, passenger cars. In terms of product performance, reliability, service life and safety protection, it is in the leading position of  the industry. Rapid response to customization requirements: Due to unified & modular software, hardware platform and rich design, application experience, to provide protection for product development. Multi-in-one products can reduce the number of connectors, wiring harness and structural parts, reduce the cost, reduce the volume and weight, and improve the reliability of the electronic control system. Multi-in-one LCGK Integrated Motor Controller products have been widely used with good market reaction.
