V5-H-C8 series is a special inverter with high-performance vector control for the stone industry launched by Shandong Lianchuang Gaoke Automation Co.,Ltd, which is widely used in equipment such as rope saws and frame saws.The product has the same excellent control performance with the international high-end inverter. This greatly meet the needs of various transmission applications in stone industry.
Sample provide:
YESSample freight payer:
BuyerTerm of payment:
T/T, L/C, D/PCustomized:
YESWarranty:
18 MonthsDelivery Time:
5-7 working days for standard series; 7-14 working days for customized AC drivesTransportation:
Express · Sea freight · Land freight · Air freightPackage:
Standard Export Package Carton/WoodAvailability:
OEM/ODM, Minmum Order RequestPlace of Origin:
ChinaShipping Port:
ShandongCertification:
CE, EAC, ISO9001, OHSAS18001, TS16949, SGSProduct Overview
Item
Description
Product Name
Frequency Inverter/ AC Drive
Model Number
V5-H-4TxxG-C8
Power Range
0.75kW-75kW
Rated Input Voltage
3 phase 380V/480V
Rated Output Voltage
3 phase 0 to rated input voltage
Input Frequency
50Hz/60Hz
Control Mode
V/F Control, Vector Control, Sensorless Vector Control, Vector Torque Control
IP Class
Standard IP20
Overload Capacity
150% 1 minute, 180% 10 seconds, 200% 0.5 second, interval: 10 minutes (inverse time lag feature)
Feature
■ Wide input voltage range
When the inverter is fully loaded, the input voltage range is 320 ~ 480V.
■ Strong anti-interference capability
Multiple inverter are installed in the same electric control cabinet with non-interference at strictly international EMC standard design.
■ Strong environment adaptiveness
The environment of stone processing is very bad with two much dust on site ,and it is easy to be not good heat dissipation or fan blocked.
■ Excellent vector control
V&T Motor VFD Strong torque under low frequency, high stability and precision, greatly meet the needs of the stone industry.
Model Explanation
Product Catalogue
V5−H−4T□□□G−C8 ; 3 Phase 400V Constant Torque/Heavy-duty Applications
Power（kW）
0.75
1.5
2.2
3.7
5.5
7.5
11
15
18.5
22
30
37
45
55
75
Motor（kW）
0.75
1.5
2.2
3.7
5.5
7.5
11
15
18.5
22
30
37
45
55
75
Output
Voltage（V）
3 phase 0～Rated Voltage
Rated Current（A）
2.5
3.8
5.5
9
13
17
24
30
39
45
60
75
91
112
150
Overload capacity
150% ;1min，180% ;10 second， 200% ;0.5 second，interval: 10 minutes (inverse time lag feature)
Input
Voltage/ frequency
3 phase 380V～480V；50Hz/60Hz
Allowable voltage range
323V～528V；Voltage imbalance：≤3% ；allowable frequency fluctuation：±5%
Rated Current（A)
3.5
6.2
9.2
14.9
21.5
27.9
39
50.3
60
69.3
86
104
124
150
201
Braking unit
Built-in as standard
Built-in as optional
IP
IP20
Cooling mode
Natural air cooling
Forced air cooling
Installation Dimension
 |
 |
V5−H−4T7.5G−C8 and below power class
V5-H-4T11G−C8 and above power class
|
Voltage |
Model |
Appearance, Installation Dimensions（mm） |
Weight （kg） |
|||||||
|
W |
H |
D |
W1 |
H1 |
D1 |
T1 |
Hole d |
|||
|
400V |
V5−H−4T0.75G−C8 |
118 |
190 |
155 |
105 |
173 |
40.8 |
3 |
5.5 |
1.5 |
|
V5−H−4T1.5G−C8 |
118 |
190 |
175 |
105 |
173 |
60.5 |
4 |
5.5 |
2.6 |
|
|
V5−H−4T2.2G−C8 |
||||||||||
|
V5−H−4T3.7G−C8 |
||||||||||
|
V5−H−4T5.5G−C8 |
155 |
249 |
185 |
136 |
232 |
69 |
8 |
5.5 |
4.5 |
|
|
V5−H−4T7.5G−C8 |
||||||||||
|
V5−H−4T11G−C8 |
210 |
337 |
200 |
150 |
324 |
88 |
2 |
7 |
8.5 |
|
|
V5−H−4T15G−C8 |
||||||||||
|
V5−H−4T18.5G−C8 |
289 |
440 |
215 |
200 |
425 |
88 |
2.5 |
7 |
17 |
|
|
V5−H−4T22G−C8 |
||||||||||
|
V5−H−4T30G−C8 |
||||||||||
|
V5−H−4T37G−C8 |
319 |
575 |
212 |
220 |
553 |
90.5 |
2.5 |
10 |
25 |
|
|
V5−H−4T45G−C8 |
||||||||||
|
V5−H−4T55G−C8 |
404 |
615 |
250 |
270 |
590 |
86.5 |
3.0 |
10 |
35 |
|
|
V5−H−4T75G−C8 |
||||||||||
Applications
 |
 |
 |
 |
 |
 |
 |
 |
 |
V&T AC Drive Representative Industry
As an advanced China VFD Drive Factory Manufacturers,The use of V&T frequency drive (VFDs): a VFD is used to regulate the speed and torque of the Motor according to the variation of the load in order to improve the Motor energy efficiency. The technology of AC-VFD-AC drives power overcomes the small range and poor speed adjustment performance. The Stone Processing Inverter of Shandong V&T Technologies Co.,Ltd. are widely used in Torque Control Inverter, Gantry Stone Saw, Rope Saw, Stone Processing, Fan, Conveyor, universal fields etc.
