V&T oil-free scroll air compressor is featured with stable performance, cleanness, no oil, low vibration and low noise. There is no need to add any oil medium in the working process, and the compressed air conforms to the highest 0 class oil-free standard of ISO-8573-1.
The scroll air compressor works continuously without any additional work. It has advantages of few accessories, simple structure, high reliability, and long service life. In the process of meeting customer demand for high-quality compressed air, we are constantly striving for higher product performance and better customer service.
Item NO.:
LCGK oil-free scrollSample provide:
YESSample freight payer:
BuyerTerm of payment:
T/T, L/C, D/PCustomized:
YESWarranty:
24 Months or 1500 Working HoursDelivery Time:
5-7 Working Days for Standard Series; 7-14 Working DaysTransportation:
Express·Sea Freight·Land Freight·Air FreightPackage:
Standard Export Package Carton/WoodAvailability:
OEM/ODM, Minimum Order RequestPlace of Origin:
ChinaShipping Port:
ShandongCertification:
CE and 0 class oil-free standard of ISO-8573-1V&T oil-free scroll air compressor is featured with stable performance, cleanness, no oil, low vibration and low noise. There is no need to add any oil medium in the working process, and the compressed air conforms to the highest 0 class oil-free standard of ISO-8573-1.The scroll air compressor works continuously without any additional work. It has advantages of few accessories, simple structure, high reliability, and long service life. In theprocessof meeting customer demand for high-quality compressed air, we are constantly striving for higher product performance and better customer service.
Features
Cleanness:Conform to the global highest standard of oil free air compressing; be clean and safe by using air.
Reliability:Less accessories, no wearing parts, long service life and less maintenance.
Energy saving:Paralleling several machines, automotive controlling specific main machine according to the actual use and no pollution.
Silence:Low noise and vibration; used for precise machines.
（1）Ambient temperature: 2°C-40°C;
（2）Relative humidity: ≤80 percent;
（3）Please avoid direct sunlight;
（4）Shall be no flammable or explosive gases or organic solvents etc.;
（5）Keep away from the place exposed to rain, dust and flotsam;
（6）Ensure that the air compressor installation space has good ventilation condition. When the ambient temperature exceeds 40 ℃, the ventilation fan forced ventilation must be used. For every 0.4 m³ of exhaust volume, an exhaust fan with an airflow of not less than 40 m³/min shall be provided.
Item
Description
Product Name
Oil free scroll air compressor
Model Number
V-3.7-8-P
Power Range
1.5kW-5.5kW
Power Supply
3 phase 380V50Hz
Applicable Motor
Asynchronous, permanent magnet synchronous, drive control machine etc.
IP Class
IP55
Overload Capacity
150% 1 minute, 180% 10 seconds, 200% 0.5 second, interval: 10 minutes (inverse time lag feature)
|
Model |
Rated Power (kW)
|
Maximum pressure MPa |
Emission Volume L/min |
Noise dB（A ） |
Dimension L*W*H （ mm） |
Weight ( kg ) |
|
V − 1.5 −8 |
1.5 |
8 |
170 |
52 |
358*350*290 |
15 |
|
V− 1.5 − 10 |
1.5 |
10 |
120 |
52 |
358*350*290 |
15 |
|
V −2.2 −8 |
2.2 |
8 |
240 |
55 |
358*350*290 |
15 |
|
V −2.2 − 10 |
2.2 |
10 |
205 |
56 |
358*350*290 |
15 |
|
V −3.7 −8 |
3.7 |
8 |
400 |
58 |
455*405*293 |
22 |
|
V −3.7 − 10 |
3.7 |
10 |
350 |
58 |
455*405*293 |
22 |
|
V −5.5 −8 |
5.5 |
8 |
600 |
70 |
422*420*355 |
25 |
|
V -5.5 - 10 |
5.5 |
10 |
550 |
70 |
422*420*355 |
25 |
(1) As a precision equipment, shall move it by forklift from the box or product bottom in the loading and unloading, moving and installation process. It shall be strictly prohibited to use the exhaust port and drain port pipe valve as the stress point to carry the air compressor.
(2) Shall remove the fixed base for transportation during installation.
(3) The air compressor must be installed on a flat and hard surface.
(4) The installation space shall meet the requirements of the following diagram in order to ensure the operation and maintenance of the air compressor.
