Is a simple sport programmable controller with 4 pulse outputs based on the VC10 series, built-in 2-way l00KHz + 2-way 60KHz high-speed pulse outputs, 2-way 50KHz high-speed counting. It has all the functions of the VC10, and optimizes and improves the performance of the product, making it extremely cost-effective.
Item NO.:
Simple Motion SmallSample provide:
YESSample freight payer:
BuyerTerm of payment:
T/T, L/C, D/PCustomized:
YesWarranty:
24 MonthsDelivery Time:
14-30 WorkingTransportation:
Express · Sea Freight · Land Freight · Air FreightPackage:
Standard Export Package Carton/WoodAvailability:
OEM/ODM, Minmum Order RequestPlace of Origin:
ChinaShipping Port:
ShandongCertification:
CE, EAC, ISO9001, OHSAS18001, TS16949, SGS
Features
·Control scale (I/O): 16-172 points（Basic unit16/24/30/40/60）
·It has all the features of the VC10 and optimizes the performance of the product
·Built-in 2-way 100KHZ+2-way 60KHz pulse output
·Built-in 2-way 50KHZ+4-way l0KHz high-speed counting
·Comes with 3 communication ports (1 way RS232 programming port, 2-way RS485)
·Excellent expandability, expansion unit see VC10 expansion section
Master Module General Specifications
|
Item |
Description |
|
Rated voltage |
100-240VAC/24VDC |
|
Allowable Voltage Range |
85-264VAC/19-30VDC |
|
Operating temperature |
-5~55°C, 10~90%(condensationless) |
|
Storage environment temperature |
-40~70℃，10〜90%（condensationless） |
|
Protection level |
IP20 |
|
Safety certification |
Designed in accordance with IEC61131-2 and UL508 standards. CE certified |
|
Product series |
Product model |
Description |
Size |
|
VC10V |
VC10V-1006BRA |
VC10V Series 10-Point Input 6-Point Relay Output Master Module（AC power supply） |
135×90×71.2 |
|
VC10V |
VC10V-1006BTA |
VC10V Series 10-Point Input 6-Point transistor Output Master Module（AC power supply） |
135×90×71.2 |
|
VC10V |
VC10V-1410BRA |
VC10V Series 14-Point Input 10-Point Relay Output Master Module（AC power supply） |
135×90×71.2 |
|
VC10V |
VC10V-1410BTA |
VC10V Series 14-Point Input 10-Point transistor Output Master Module（AC power supply） |
135×90×71.2 |
|
VC10V |
VC10V-1614BRA |
VC10V Series 16-Point Input 14-Point Relay Output Master Module（AC power supply） |
150×90×71.2 |
|
VC10V |
VC10V-1614BTA |
VC10V Series 16-Point Input 14-Point transistor Output Master Module（AC power supply） |
150×90×71.2 |
|
VC10V |
VC10V-1614BRA1 |
16-point input and 14-point relay output master module with integrated 2-in-1-out analogue function（AC power supply） |
182×90×71.2 |
|
VC10V |
VC10V-2416BRA |
VC10V Series 24-Point Input 16-Point relay Output Master Module（AC power supply） |
182×90×71.2 |
|
VC10V |
VC10V-2416BTA |
VC10V Series 24-Point Input 16-Point transistor Output Master Module（AC power supply） |
182×90×71.2 |
I/O Expansion Module
|
Product series |
Product model |
Description |
Size |
|
VC10 |
VC10-0808ERN |
VC10V Series 8-Point Input 8-Point relay Output expansion module |
61×90×71.2 |
|
VC10 |
VC10-0808ETN |
VC10V Series 8-Point Input 8-Point transistor Output expansion module |
61×90×71.2 |
|
VC10 |
VC10-1600ENN |
VC10 series 16-point input expansion module |
61×90×71.2 |
|
VC10 |
VC10-0016ETN |
VC10 series 16-point transistor output expansion module |
61×90×71.2 |
|
VC10 |
VC10-0016ERN |
VC10 series 16-point relay output expansion module |
61×90×71.2 |
Master Module Main Performance Specifications
|
Item |
Specification |
||
|
Implementation method |
|
Cycle scan+interrupt method
|
|
|
Programming method |
|
Instruction, ladder diagram, sequential function diagram
|
|
|
Instruction Type |
Basic instruction |
32pcs |
|
|
Application instruction |
226pcs |
||
|
Implementation time |
Basic instruction |
0.3 μs |
|
|
Application instruction |
Several μs~ Hundreds μs |
||
|
Program capacity |
|
12K steps |
|
|
Max expansion |
|
7 expansion modules, including I/O expansion module and special function module |
|
|
Input relay(X) |
|
X0〜X177, 128 points，octal code |
|
|
Output relay(Y) |
|
Y0~Y177, 128 points，octal code |
|
|
Auxiliary relay(M) |
|
M0-M2047, 2048 points |
|
|
Local auxiliary relay(LM) |
|
LM0-LM63, 64 points |
|
|
Special auxiliary relay (SM) |
|
SM0 〜SM255, 256 points |
|
|
Status relay (S) |
|
S0-S1023, 1024 points |
|
|
Timer(T) |
|
256 points (T0-T255) |
100ms precision: T0 〜T209, 210 pcs |
|
10ms precision: T210~T251,42pcs |
|||
|
1ms precision: T252~T255,4pcs |
|||
|
Counter(C) |
|
256 points (C0-C255)
|
16-bit incremental count: C0~C199,200pcs |
|
32-bit increment/decrement count: C200 ~ C235, 36pcs |
|||
|
32-bit high speed count: C236~C255,20pcs |
|||
|
Data register(D) |
|
D0 ~ D7999, 8000 points
|
|
|
Local data register(V) |
|
V0-V63, 64 points
|
|
|
Variable address register(Z) |
|
Z0-Z15, 16 points
|
|
|
Special data register(SD) |
|
SD0-SD255, 256 points
|
|
|
Power-off retention register |
|
M,S,D,C components, 500 bit components, 650 word components can be saved |
|
|
Storage media |
|
EEPROM+FLASH
|
|
|
High-speed counter |
|
Single phase: 6sets,2×50KHz+4×10KHz Two phase: 2 sets, 1×30KHz+1×5KHz |
|
|
Pulse output |
|
Two independent 100KHz outputs, 2-way 60KHz outputs |
|
|
Interrupt resources |
External Input Interrupt High-speed counter interrupt Timer interrupt Communication interrupt Pulse interrupt Power loss interrupt |
16pcs (X0-X7, 8-way supports rising and falling edges) 6pcs 3pcs 8pcs 2pcs 1pcs |
|
|
Pulse capture |
|
8-way, X0-X1: 20μs, X2-X7: 100μs
|
|
|
Digital filtration |
|
X0-X7 provide digital filtering, filtering time(ms): 0, 8, 16, 32, 64. other hardware filters |
|
|
Communication port |
|
3-way（1 way is R5-232, 2 ways are RS-485） |
|
