V5−BA series is a high-performance vector control inverter launched by V&T for spinning frame in textile industry. The product adopts the open-loop vector control technology with the current international advanced technology, which has the same excellent control performance with the international high-end inverter.
Sample provide:
YESSample freight payer:
BuyerTerm of payment:
T/T, L/C, D/PCustomized:
YESWarranty:
18 MonthsDelivery Time:
5-7 working days for standard series; 7-14 working days for customized AC drivesTransportation:
Express · Sea freight · Land freight · Air freightPackage:
Standard Export Package Carton/WoodAvailability:
OEM/ODM, Minmum Order RequestPlace of Origin:
ChinaShipping Port:
ShandongCertification:
CE, EAC, ISO9001, OHSAS18001, TS16949, SGSProduct Overview
| Product Name | Frequency Inverter/ AC Drive |
| Model Number | V5-BA-4Txx |
| Power Range | 7.5kW-90kW |
| Rated Input Voltage | 3 phase 380V/480V |
| Rated Output Voltage | 3 phase 0 to rated input voltage |
| Input Frequency | 50Hz/60Hz |
| Applicable Motor | Asynchronous Motor |
| Control Mode | V/F Control, Vector Control, Sensor-less Vector Control |
| Communication | Modbus 485 RTU |
| Protection Class | Standard IP20 |
| Overload Capacity | 150% 1 minute, 180% 10 seconds, 200% 0.5 second, interval: 10 minutes (inverse time lag feature) |
Feature
■ Designed for requirements of spinning frames in textile machinery with convenient installation outside cabinet;
■ Textile Inverter is suitable for dusty industrial sites, and the radiator is easy to clean;
■ After the inverter temperature exceeds the set value, it reminds the user to clean the radiator and fan;
■ Easy to operate, single button to stop, being zero on full yarn and wire break;
■ Built-in swing frequency function can output triangle frequency and kick frequency to prevent yarn overlap and facilitate unwinding;
■ Stop automatically to avoid wire break after the pulse feedback signal misses;
Model Explanation
Product Catalog
V5−BA−4T□□□ ;
|
Power (kW) |
7.5 |
11 |
15 |
18.5 |
22 |
30 |
37 |
45 |
55 |
75 |
90 |
|
|
Adapter motor power (kW) |
7.5 |
11 |
15 |
18.5 |
22 |
30 |
37 |
45 |
55 |
75 |
90 |
|
|
Output |
Voltage (V) |
3-phase 0 to rated input voltage |
||||||||||
|
Rated current (A) |
17 |
22 |
30 |
37 |
44 |
56 |
72 |
91 |
110 |
142 |
176 |
|
|
Overload capability |
115% 1 minute, 160% 0.5 seconds, interval 10 minutes (inverse time characteristic) |
|||||||||||
|
Input |
Rated voltage / frequency |
3-phase 380V/480V; 50Hz/60Hz |
||||||||||
|
Allowable voltage range |
323V ~ 528V; voltage imbalance: ≤ 3%; allow frequency fluctuation: ± 5% |
|||||||||||
|
Rated current (A) |
19 |
26 |
33 |
41 |
48 |
62 |
79 |
100 |
121 |
156 |
194 |
|
|
Brake unit |
Built-in as standard |
Built-in as optional |
||||||||||
|
IP Class |
IP 20 |
|||||||||||
|
Cooling method |
Forced air cooling |
|||||||||||
Model table
|
Voltage |
Model |
Three-phase 400V Variable torque / light load application |
||
|
Motor (kW) |
Rated output current (A) |
Rated input current (A) |
||
|
400V |
V5−BA−4T7.5 |
7.5 |
17 |
27.9 |
|
V5−BA−4T11 |
11 |
24 |
39 |
|
|
V5−BA−4T15 |
15 |
30 |
50.3 |
|
|
V5−BA−4T18.5 |
18.5 |
37 |
60 |
|
|
V5−BA−4T22 |
22 |
44 |
69.3 |
|
|
V5−BA−4T30 |
30 |
56 |
86 |
|
|
V5−BA−4T37 |
37 |
72 |
104 |
|
|
V5−BA−4T45 |
45 |
91 |
124 |
|
|
V5−BA−4T55 |
55 |
110 |
150 |
|
|
V5−BA−4T75 |
75 |
142 |
190 |
|
|
V5−BA−4T90 |
90 |
176 |
235 |
|
Installation Dimension
V5−BA series Outline and installation dimensions and approximate weight
|
Voltage |
Model |
Outline and installation dimensions (mm) |
weight (kg) |
|||||||
|
W |
H |
D |
W1 |
H1 |
D1 |
W2 |
Hole d |
|||
|
V5−BA−4T7.5 |
206 |
303 |
153 |
166 |
251 |
96 |
136 |
8 |
6.5 |
|
|
V5−BA−4T11 |
||||||||||
|
V5−BA−4T15 |
236 |
386 |
201 |
236 |
318 |
102 |
170 |
8 |
9.5 |
|
|
V5−BA−4T18.5 |
||||||||||
|
V5−BA−4T22 |
345 |
483 |
238 |
295 |
410 |
130 |
220 |
8 |
18 |
|
|
V5−BA−4T30 |
||||||||||
|
V5−BA−4T37 |
||||||||||
|
V5−BA−4T45 |
400 |
610 |
297 |
340 |
520 |
183 |
260 |
10 |
30 |
|
|
V5−BA−4T55 |
||||||||||
|
V5−BA−4T75 |
470 |
639 |
302 |
410 |
545 |
183 |
320 |
10 |
40 |
|
|
V5−BA−4T90 |
||||||||||
V5−BA−57 series Outline and installation dimensions and approximate weight
|
Voltage |
Model |
Outline and installation dimensions (mm) |
weight (kg) |
|||||||
|
W |
H |
D |
W1 |
H1 |
D1 |
W2 |
Hole d |
|||
|
V5−BA−4T7.5−57 |
206 |
303 |
185 |
166 |
251 |
96 |
136 |
8 |
7.5 |
|
|
V5−BA−4T11−57 |
||||||||||
|
V5−BA−4T15−57 |
286 |
386 |
245 |
226 |
308 |
102 |
170 |
8 |
10.5 |
|
|
V5−BA−4T18.5−57 |
||||||||||
|
V5−BA−4T22−57 |
345 |
482 |
286 |
285 |
400 |
130 |
220 |
8 |
19 |
|
|
V5−BA−4T30−57 |
||||||||||
|
V5−BA−4T37−57 |
||||||||||
|
V5−BA−4T45−57 |
400 |
610 |
343 |
330 |
520 |
183 |
260 |
10 |
31 |
|
|
V5−BA−4T55−57 |
||||||||||
|
V5−BA−4T75−57 |
470 |
639 |
350 |
400 |
545 |
183 |
320 |
10 |
41 |
|
|
V5−BA−4T90−57 |
||||||||||
Optional Expansion Card
|
Category |
Name |
Model |
Function Description |
reference |
|
Operation panel |
Operation panel (shuttle type) |
V6−DP01 |
Full range of models |
P2−** |
|
Operation panel (button type) |
V6−DP02 |
Full range of models |
P2−** |
|
|
Text display |
EX−MT01 |
Man-machine interface - text display |
P2−** |
|
|
touch screen |
EX−MT02 |
Human-machine interface - touch screen |
P2−** |
|
|
Fake panel |
V6−DP03 |
Customer option |
P2−** |
|
|
Pallet |
V6−DP05 |
Operation panel mounting accessories |
P2−** |
|
|
Expansion Card |
Power monitoring card |
EX−PA01 |
Three-phase input power supply phase loss / instantaneous power failure monitoring |
P2−** |
|
Phase detection card |
EX−PA02 |
Three-phase input power phase detection |
P2−** |
|
|
External power rectifier card |
EX−RF01 |
Control power is provided by external power supply |
P2−** |
|
|
Programmable CAN bus expansion card |
EX−CA05 |
; |
P2−** |
|
|
Profibus DP communication card |
EX−CA06 |
; |
P2−** |
|
|
Keyboard extension cord |
2 m keyboard extension cable |
CB1−200 |
; |
P2−** |
|
3 m keyboard extension cable |
CB1−300 |
; |
P2−** |
Applications
 |
 |
 |
 |
 |
 |
 |
 |
|
Textile Industry Automation Application
The textile spinning frame can also be used in other industries where dust is frequently cleaned. Variable frequency drives (VFDs) or Customize VFD Drive regulate the rotational force and speed of electric motors by changing the frequency of the input power to the motor. V&T Inverter Drive Solution of Shandong V&T Technologies Co.,Ltd. are widely used in Spinning Machine, Weave Machine, Knitting Machine.
